KC3225K,KC3225K24.5760C1GE00,24.576MHz,3225mm,Kyocera晶振

当前位置：首页 » 日产晶振 » 京瓷晶振 » KC3225K,KC3225K24.5760C1GE00,24.576MHz,3225mm,Kyocera晶振

prevnext

KC3225K,KC3225K24.5760C1GE00,24.576MHz,3225mm,Kyocera晶振

频率：24.576MHz

尺寸：3.2x2.5mm

KC3225K,KC3225K24.5760C1GE00,24.576MHz,3225mm,Kyocera晶振，日本进口晶振，Kyocera晶振，京瓷晶振，型号：KC3225K系列晶振，编码为：KC3225K24.5760C1GE00，电压：1.6V~3.63V，CMOS输出晶振，频率为：24.576MHz，工作温度范围：-40℃至+85℃，小体积晶振尺寸：3.2x2.5mm表面贴装，四脚贴片晶振，有源晶振，石英晶振，石英晶体振荡器，SMD水晶振动子，时钟晶体振荡器。具有超小型晶振，轻薄型晶振，高可靠性晶振，高品质晶振，高质量等特点。应用于：通讯设备晶振，无线蓝牙晶振，汽车电子晶振，网络晶振，导航仪晶振，工业设备等应用。

订购热线：86-0755-27838351

KC3225K,KC3225K24.5760C1GE00,24.576MHz,3225mm,Kyocera晶振，产品特点：

●对应频率1.5~160MHz

●CMOS输出石英晶体振荡器

●电源电压1.6V~3.63V

●低电流消耗类型

●低相位噪声

KC3225K,KC3225K24.5760C1GE00,24.576MHz,3225mm,Kyocera晶振,参数表

KC3225K,KC3225K24.5760C1GE00,24.576MHz,3225mm,Kyocera晶振,尺寸图

原厂编码	晶振厂家	系列	频率	电压	工作温度
KC3225K40.0000C1GE00	Kyocera京瓷	KC3225K	40MHz	1.6 V ~ 3.63 V	-40°C ~ 85°C
KC3225K20.0000C1GE00	Kyocera京瓷	KC3225K	20MHz	1.6 V ~ 3.63 V	-40°C ~ 85°C
KC3225K27.0000C1GE00	Kyocera京瓷	KC3225K	27MHz	1.6 V ~ 3.63 V	-40°C ~ 85°C
KC3225K32.0000C1GE00	Kyocera京瓷	KC3225K	32MHz	1.6 V ~ 3.63 V	-40°C ~ 85°C
KC3225K33.3333C1GE00	Kyocera京瓷	KC3225K	33.3333MHz	1.6 V ~ 3.63 V	-40°C ~ 85°C
KC3225K48.0000C1GE00	Kyocera京瓷	KC3225K	48MHz	1.6 V ~ 3.63 V	-40°C ~ 85°C
KC3225K50.0000C1GE00	Kyocera京瓷	KC3225K	50MHz	1.6 V ~ 3.63 V	-40°C ~ 85°C
KC3225K1.84320C1GE00	Kyocera京瓷	KC3225K	1.8432MHz	1.6 V ~ 3.63 V	-40°C ~ 85°C
KC3225K7.37280C1GE00	Kyocera京瓷	KC3225K	7.3728MHz	1.6 V ~ 3.63 V	-40°C ~ 85°C
KC3225K8.00000C1GE00	Kyocera京瓷	KC3225K	8MHz	1.6 V ~ 3.63 V	-40°C ~ 85°C
KC3225K10.0000C1GE00	Kyocera京瓷	KC3225K	10MHz	1.6 V ~ 3.63 V	-40°C ~ 85°C
KC3225K12.0000C1GE00	Kyocera京瓷	KC3225K	12MHz	1.6 V ~ 3.63 V	-40°C ~ 85°C
KC3225K14.7456C1GE00	Kyocera京瓷	KC3225K	14.7456MHz	1.6 V ~ 3.63 V	-40°C ~ 85°C
KC3225K18.4320C1GE00	Kyocera京瓷	KC3225K	18.432MHz	1.6 V ~ 3.63 V	-40°C ~ 85°C
KC3225K32.7680C1GE00	Kyocera京瓷	KC3225K	32.768MHz	1.6 V ~ 3.63 V	-40°C ~ 85°C
KC3225K33.0000C1GE00	Kyocera京瓷	KC3225K	33MHz	1.6 V ~ 3.63 V	-40°C ~ 85°C
KC3225K60.0000C1GE00	Kyocera京瓷	KC3225K	60MHz	1.6 V ~ 3.63 V	-40°C ~ 85°C
KC3225K66.6667C1GE00	Kyocera京瓷	KC3225K	66.6667MHz	1.6 V ~ 3.63 V	-40°C ~ 85°C
KC3225K24.0000C1GE00	Kyocera京瓷	KC3225K	24MHz	1.6 V ~ 3.63 V	-40°C ~ 85°C
KC3225K16.0000C1GE00	Kyocera京瓷	KC3225K	16MHz	1.6 V ~ 3.63 V	-40°C ~ 85°C
KC3225K80.0000C1GE00	Kyocera京瓷	KC3225K	80MHz	1.6 V ~ 3.63 V	-40°C ~ 85°C
KC3225K24.5760C1GE00	Kyocera京瓷	KC3225K	24.576MHz	1.6 V ~ 3.63 V	-40°C ~ 85°C
KC3225K3.68640C1GE00	Kyocera京瓷	KC3225K	3.6864MHz	1.6 V ~ 3.63 V	-40°C ~ 85°C
KC3225K4.00000C1GE00	Kyocera京瓷	KC3225K	4MHz	1.6 V ~ 3.63 V	-40°C ~ 85°C
KC3225K14.3182C1GE00	Kyocera京瓷	KC3225K	14.3182MHz	1.6 V ~ 3.63 V	-40°C ~ 85°C
KC3225K16.3840C1GE00	Kyocera京瓷	KC3225K	16.384MHz	1.6 V ~ 3.63 V	-40°C ~ 85°C
KC3225K2.04800C1GE00	Kyocera京瓷	KC3225K	2.048MHz	1.6 V ~ 3.63 V	-40°C ~ 85°C
KC3225K22.5792C1GE00	Kyocera京瓷	KC3225K	22.5792MHz	1.6 V ~ 3.63 V	-40°C ~ 85°C
KC3225K28.6364C1GE00	Kyocera京瓷	KC3225K	28.6364MHz	1.6 V ~ 3.63 V	-40°C ~ 85°C
KC3225K75.0000C1GE00	Kyocera京瓷	KC3225K	75MHz	1.6 V ~ 3.63 V	-40°C ~ 85°C
KC3225K12.2880C1GE00	Kyocera京瓷	KC3225K	12.288MHz	1.6 V ~ 3.63 V	-40°C ~ 85°C
KC3225K25.0000C1GE00	Kyocera京瓷	KC3225K	25MHz	1.6 V ~ 3.63 V	-40°C ~ 85°C
KC3225K11.2896C1GE00	京瓷晶振	KC3225K	11.2896MHz	1.6 V ~ 3.63 V	-40°C ~ 85°C
KC3225K13.5600C1GE00	Kyocera京瓷	KC3225K	13.56MHz	1.6 V ~ 3.63 V	-40°C ~ 85°C
KC3225K1.84320C10E00	Kyocera京瓷	KC3225K	1.8432MHz	1.6 V ~ 3.63 V	-10°C ~ 70°C
KC3225K2.04800C10E00	Kyocera京瓷	KC3225K	2.048MHz	1.6 V ~ 3.63 V	-10°C ~ 70°C
KC3225K3.68640C10E00	Kyocera京瓷	KC3225K	3.6864MHz	1.6 V ~ 3.63 V	-10°C ~ 70°C
KC3225K4.00000C10E00	Kyocera京瓷	KC3225K	4MHz	1.6 V ~ 3.63 V	-10°C ~ 70°C
KC3225K7.37280C10E00	Kyocera京瓷	KC3225K	7.3728MHz	1.6 V ~ 3.63 V	-10°C ~ 70°C
KC3225K8.00000C10E00	Kyocera京瓷	KC3225K	8MHz	1.6 V ~ 3.63 V	-10°C ~ 70°C
KC3225K10.0000C10E00	Kyocera京瓷	KC3225K	10MHz	1.6 V ~ 3.63 V	-10°C ~ 70°C
KC3225K11.2896C10E00	Kyocera京瓷	KC3225K	11.2896MHz	1.6 V ~ 3.63 V	-10°C ~ 70°C
KC3225K12.0000C10E00	Kyocera京瓷	KC3225K	12MHz	1.6 V ~ 3.63 V	-10°C ~ 70°C
KC3225K12.2880C10E00	Kyocera京瓷	KC3225K	12.288MHz	1.6 V ~ 3.63 V	-10°C ~ 70°C
KC3225K13.5600C10E00	Kyocera京瓷	KC3225K	13.56MHz	1.6 V ~ 3.63 V	-10°C ~ 70°C
KC3225K14.3182C10E00	Kyocera京瓷	KC3225K	14.3182MHz	1.6 V ~ 3.63 V	-10°C ~ 70°C
KC3225K14.7456C10E00	Kyocera京瓷	KC3225K	14.7456MHz	1.6 V ~ 3.63 V	-10°C ~ 70°C
KC3225K16.0000C10E00	Kyocera京瓷	KC3225K	16MHz	1.6 V ~ 3.63 V	-10°C ~ 70°C
KC3225K16.3840C10E00	Kyocera京瓷	KC3225K	16.384MHz	1.6 V ~ 3.63 V	-10°C ~ 70°C
KC3225K18.4320C10E00	Kyocera京瓷	KC3225K	18.432MHz	1.6 V ~ 3.63 V	-10°C ~ 70°C
KC3225K20.0000C10E00	Kyocera京瓷	KC3225K	20MHz	1.6 V ~ 3.63 V	-10°C ~ 70°C
KC3225K22.5792C10E00	Kyocera京瓷	KC3225K	22.5792MHz	1.6 V ~ 3.63 V	-10°C ~ 70°C
KC3225K24.0000C10E00	Kyocera京瓷	KC3225K	24MHz	1.6 V ~ 3.63 V	-10°C ~ 70°C
KC3225K24.5760C10E00	Kyocera京瓷	KC3225K	24.576MHz	1.6 V ~ 3.63 V	-10°C ~ 70°C
KC3225K25.0000C10E00	Kyocera京瓷	KC3225K	25MHz	1.6 V ~ 3.63 V	-10°C ~ 70°C
KC3225K27.0000C10E00	Kyocera京瓷	KC3225K	27MHz	1.6 V ~ 3.63 V	-10°C ~ 70°C
KC3225K28.6364C10E00	Kyocera京瓷	KC3225K	28.6364MHz	1.6 V ~ 3.63 V	-10°C ~ 70°C
KC3225K32.0000C10E00	Kyocera京瓷	KC3225K	32MHz	1.6 V ~ 3.63 V	-10°C ~ 70°C
KC3225K32.7680C10E00	Kyocera京瓷	KC3225K	32.768MHz	1.6 V ~ 3.63 V	-10°C ~ 70°C
KC3225K33.0000C10E00	Kyocera京瓷	KC3225K	33MHz	1.6 V ~ 3.63 V	-10°C ~ 70°C
KC3225K33.3333C10E00	Kyocera京瓷	KC3225K	33.3333MHz	1.6 V ~ 3.63 V	-10°C ~ 70°C
KC3225K40.0000C10E00	Kyocera京瓷	KC3225K	40MHz	1.6 V ~ 3.63 V	-10°C ~ 70°C
KC3225K48.0000C10E00	Kyocera京瓷	KC3225K	48MHz	1.6 V ~ 3.63 V	-10°C ~ 70°C
KC3225K50.0000C10E00	Kyocera京瓷	KC3225K	50MHz	1.6 V ~ 3.63 V	-10°C ~ 70°C
KC3225K60.0000C10E00	Kyocera京瓷	KC3225K	60MHz	1.6 V ~ 3.63 V	-10°C ~ 70°C
KC3225K66.6667C10E00	Kyocera京瓷	KC3225K	66.6667MHz	1.6 V ~ 3.63 V	-10°C ~ 70°C
KC3225K75.0000C10E00	Kyocera京瓷	KC3225K	75MHz	1.6 V ~ 3.63 V	-10°C ~ 70°C
KC3225K80.0000C10E00	Kyocera京瓷	KC3225K	80MHz	1.6 V ~ 3.63 V	-10°C ~ 70°C
